Which Buffing Wheels To Use

This forum is for those who like to repair and restore knives, and for those who would like to learn.
Jeffinn
Posts: 73
Joined: Fri Nov 10, 2017 3:16 am
Location: Roseville, Mi

Which Buffing Wheels To Use

Postby Jeffinn » Wed Dec 06, 2017 9:23 pm

I just recently acquired a bench buffer (Harbor Freight 3450 rpm model, not ideal I know but will hopefully it will work for now). I'm looking at the numerous buffing wheels that are available and its getting a bit confusing. Is there a decent all purpose 6" buffing wheel that I can purchase to get started or do I need three or four different kinds? I'm seeing Muslim wheels, sewed wheels in 60 ply or 80 ply, sisal wheels etc.
Most of my polishing work currently revolves around polishing nickel silver bolsters and brass liners.
Thanks.
Jeff
If it ain't broke, you're not trying!

User avatar
americanedgetech
Gold Tier
Gold Tier
Posts: 1528
Joined: Mon Sep 04, 2017 1:40 am
Location: Florida Pan Handle
Contact:

Re: Which Buffing Wheels To Use

Postby americanedgetech » Wed Dec 06, 2017 9:45 pm

You're gonna shake your head on this answer...
I have a Delta 8" that I bought on FleaBay for 99.00. With this (so far) I have three wheels that I made from MDF (fiber board).
The first is plain wood to be used with compounds on blades for crisp definition on edges, and grind lines.

The second I rubber cemented Scotch Brite from a roll onto. I have three grades to use, and it is less expensive than buying the pre made scotch brite buffing pads, the third I cemented an old leather belt to for fast stropping.

The remainder of the cloth wheels I have to buy still but from what little I do know you want wheels as firm as you can find them in sewn multi ply for the early stages in polishing, and one wheel for each gritt of compound you will use (2-3 wheels).
Finally 2-3 soft wheels for handle materials that will burn or pull like the plastics or synthetics that you are working with.

Now I am a beginner on knives but I have a bunch of years of polishing everything I could find. Mainly stainless, bronze, brass, hi/'low carbon steels, wood, glass, plastics, ect...

I figure for my methods, and the way I work that 9-10 different purposed wheels will do everything that I am wanting to do.
Much the same as grinder belts. The more stages you divide your finish work into the better the end result, and the less physical work that needs to be done.

I anxiously await the fellas that have been working on knives for a long time to chime in. I know what works for me but I am always open to trying new methods that I have not learned or thought of.
Ken Mc.

WTB Kershaw 2120 MACHO Lockback Parts knife
I need a pile side scale. THX!

User avatar
tongueriver
Gold Tier
Gold Tier
Posts: 2656
Joined: Tue Sep 16, 2008 8:01 pm

Re: Which Buffing Wheels To Use

Postby tongueriver » Wed Dec 06, 2017 10:39 pm

I hope to read more, also. I have a Harbor Freight benchgrinder with two eight inch wheels @ 3450 rpm. I must run a nut off/on to change the wheels. I would like to know what to buy as well, especially to maintain crisp grind lines on fixed blade hunting knives. I know nothing about this subject. This could be a good thread?
Cal Pruett is my name; trad knives is my game. Always interested pre-war Schrade CutCo knives & always have dozens others eclectic mix to trade/sell

User avatar
americanedgetech
Gold Tier
Gold Tier
Posts: 1528
Joined: Mon Sep 04, 2017 1:40 am
Location: Florida Pan Handle
Contact:

Re: Which Buffing Wheels To Use

Postby americanedgetech » Wed Dec 06, 2017 11:16 pm

Crisp lines = hard tools.
Wooden wheels were used well before anyone thought of using cloth, and with todays engineered woods (MDF) they are stable, and uniform.
Paper, then felt wheels are next in line but I have zero experience with them.
Ken Mc.

WTB Kershaw 2120 MACHO Lockback Parts knife
I need a pile side scale. THX!

User avatar
muskrat man
Gold Tier
Gold Tier
Posts: 5346
Joined: Fri Jun 30, 2006 4:04 am
Location: Ohio
Contact:

Re: Which Buffing Wheels To Use

Postby muskrat man » Thu Dec 07, 2017 3:18 pm

I like a sewed muslin wheel for general purpose and use a hard sisal wheel with cutting (aggressive) compounds for starting finishes on blades and other steel parts.
Those who would sacrifice liberty for security deserve neither and will lose both.

Custom knives, repair, restoration & embellishment
Certified Hubertus, Taylor, & Schrade repairman past and present
http://www.muskratmanknives.com

Jeffinn
Posts: 73
Joined: Fri Nov 10, 2017 3:16 am
Location: Roseville, Mi

Re: Which Buffing Wheels To Use

Postby Jeffinn » Thu Dec 07, 2017 4:28 pm

muskrat man wrote:I like a sewed muslin wheel for general purpose and use a hard sisal wheel with cutting (aggressive) compounds for starting finishes on blades and other steel parts.


Thanks Muskrat Man. That helps me narrow it down a bit.
Jeff
If it ain't broke, you're not trying!

User avatar
americanedgetech
Gold Tier
Gold Tier
Posts: 1528
Joined: Mon Sep 04, 2017 1:40 am
Location: Florida Pan Handle
Contact:

Re: Which Buffing Wheels To Use

Postby americanedgetech » Thu Dec 07, 2017 5:46 pm

From the Caswell web site: http://www.caswellplating.com/buffing-p ... heels.html
"SISAL WHEELS
Sisal is a slender, hard, cellular strand of fiber that has demonstrated its great strength and tough resiliency in the form of binder twine, cord & rope for many years. These qualities, along with its natural abrading and grease absorbing characteristics, provide an ideal buffing wheel fabric.

Sisal buffing wheels will provide both polishing and cutting action. They will remove stretcher strains, orange peel, polishing wheel grit lines, light die marks, etc.

To effect a fast cut, use a sisal wheel with the Black Emery compound."
Attachments
Ken Mc.

WTB Kershaw 2120 MACHO Lockback Parts knife
I need a pile side scale. THX!

User avatar
orvet
Gold Tier
Gold Tier
Posts: 15003
Joined: Tue May 16, 2006 6:23 am
Location: Willamette Valley, Oregon

Re: Which Buffing Wheels To Use

Postby orvet » Thu Dec 07, 2017 6:18 pm

Hi Jeff,
I started this to answer your PM from yesterday and then started having issues with Comcast so I was off-line for a while. I see that you started a post in the Knife Repair forums so I will answer it here since no doubt other people have the same questions.

I am not an expert at buffing but I have developed a few tricks that I use in the 12 years or so that I've been repairing and customizing knives.

I have one of those Harbor Freight buffers and I rarely use it because of the speed. I prefer a buffer around 1700 RPM, about half of the 3450 RPM the Harbor Freight model has. When I use the Harbor Freight buffer I use 4 inch and 6 inch muslin wheels. I tried an 8 inch wheel on that buffer and it wanted to fly to the moon! My go to buffer is a 1 hp Jet that runs in 1725 RPMs. I also have two homemade buffers that work very nicely, they are all preferable to me over the high-speed Harbor Freight buffer.
If you want the mathematical explanation I'm sure somebody will give it to you but basically the larger the wheel and the higher the RPMs the more surface area comes in contact with the piece you are buffing in a given period of time. And the more surface area that contacts your work the more friction it creates and the hotter it gets. What I have experienced with larger faster wheels, especially when they are hard, is that the material I am buffing tends to chatter and it does not give me as smooth finish as I would like.

Things that I have learned over the years using a buffer:
1 – The most dangerous piece of equipment in my shop is my buffer. I need to be familiar with all of the safety procedures and proper use techniques and use the guards provided. This is the only piece of equipment in my shop that has the potential of hurling a missile across the room at the speed of an arrow or maybe even a bullet! Always respect the buffer!

2 – When operating the buffer I always avoid loose clothing! I avoid anything hanging around my neck, loose sleeves, an unbuttoned shirt, frayed gloves or anything else because even at lower speeds a buffer can grab a piece of clothing and draw the operator into it almost instantaneously. A frayed glove can get caught and remove the operators finger.

3 – Avoid pushing hard on the wheel. There are exceptions to this but it’s analogous to cutting something with a dull knife, the harder you push the less control you have over the outcome. When you are exerting a lot of pressure on the wheel it is easier for the wheel to grab the work and flip it out of your hands, thus creating the missile situation. But aside from that I get better results on my work by not pressing is hard. Sometimes pressing too hard can “tear” the metal. There are certain types rouge that will help avoid that. I generally consult the catalog of the company I’m purchasing from to see what type of rouge I need.

4 – I have separate buffs for brass and nickel silver from steel buffs. There is a very simple reason for this; steel is much harder than brass or nickel silver. One little sliver of steel embedded in a wheel can ruin a piece of brass that you’re trying to polish. At best it will leave a whole bunch of scratches that you will need to spend a lot of time with to get removed.

5 – I use the harder sewn wheels for cutting and deep scratch removal. After I have the scratches removed for polishing I usually use a more loosely sewn muslin buff ideally with about four sewn rings instead of being sewn in concentric circles all the way out to the edge. And for a final finish I usually have a very muslin buff with a very fine rouge, No Scratch Pink is one I use frequently, for the final polish and gloss.

6 – These are the wheels and buffs I use. I’m sure there are other methods at least as effective probably more so, but this is the order I use from heavy cutting to fine polishing. Note that not every step is appropriate for every material you will be buffing!
A – For heavy cutting I will use a sisal wheel with emery rouge.
B – My next step would be a sewn muslin buff with the emery on it.
C – The next finer step is a sewn muslin buff with black magic rouge.
D – After that I go to a sewn buff with No Scratch Pink rouge.
E – For the final gloss and finish I will use a loose buff with No Scratch Pink.

Step A is something I usually only need to use on steel, rarely on brass or nickel silver.
Step B I will use on steel as well as rough nickel silver and brass.
Step C I use on both nickel silver, brass and steel. I have buff with black magic rouge for steel and one for nickel silver/brass. (Actually I have multiples but that’s not necessary to begin with).
Step D I will use on steel and brass/nickel silver but I will also have a separate sewn buff that I use strictly for bone/ivory/horn. If you buff metal and then bone or ivory you will have all this nasty rouge in the pores of the ivory and in the canals of the bone really drive you nuts!
Step E is my final finish for bone, stag, ivory and horn as well as for brass/nickel silver. (As those are separate buffs!)
Step F I know I didn’t have a step F up above but there is one more buff I use and that is a loose muslin buff that I used to apply carnauba wax on handles.
Step G this is a very special buff that is made from string, not from muslin. The strings are basically loops of the heavy thread. You apply a special rouge for plastic and it does a great job on the various plastics you encounter working on knives. The strings have less contact with the surface of the handle that a muslin would and that translates into less heat and no melted handles.

This is the way it I use my buffers and somewhere there are pictures of a new buffer I built that actually has three speeds. I love being able to use the lower speeds because I think it works better than high speeds and there is less heat buildup.

I do have felt wheels and the lot of other special application wheels but I think you would be able to do most everything with a couple of good rouges and some muslin wheels.
If I were going to set up to buff brass I would use black magic and no scratch pink on a hard sewn or a medium sewn wheel. If you have a hard sewn muslin wheel, you can always soften it a little bit by taking out a couple rows of stitching. In my experience softer wheels tend to make better contact to polish a contoured item as opposed to something that is flat.

In your PM you said you would welcome any advice I can give you. I’m not sure that I am expert enough to say this is the only way to do it, I can just tell you what works for me in all the years that I’ve used it.

I hope this is helpful and if you have any more questions post them here and I will be happy to add what I can. I will however be gone this weekend because I’ve got a knife show so don’t expect any answers this weekend.
Dale
AAPK Administrator

orvet@comcast.net
Please visit my AAPK store: www.allaboutpocketknives.com/orvet

"Buy more ammo!" - Johnnie Fain

Jeffinn
Posts: 73
Joined: Fri Nov 10, 2017 3:16 am
Location: Roseville, Mi

Re: Which Buffing Wheels To Use

Postby Jeffinn » Thu Dec 07, 2017 6:29 pm

Thanks Dale! Lots of good info in your very informative post and it will help me a lot. Good luck at the knife show!
Jeff
If it ain't broke, you're not trying!

User avatar
americanedgetech
Gold Tier
Gold Tier
Posts: 1528
Joined: Mon Sep 04, 2017 1:40 am
Location: Florida Pan Handle
Contact:

Re: Which Buffing Wheels To Use

Postby americanedgetech » Thu Dec 07, 2017 6:59 pm

I can help with a speed controller if anyone needs information on how to make one for a 110 or 220 volt single phase motor.

The component parts are readily available for around 40-50 bucks, and you use whatever enclosure box you wish or you can buy one for around 20 bucks more.
These will control any 110/220 volt single phase motor up to 5 Hp or heating element up to 7,500 watts/30 amp. I've built several of them and have not had a problem on anything I use them on.

Basically they are a phase modifier that shortens the 60hz cycle on one leg of the input from 60hz to 0hz or anywhere in between. They are reliable, and inexpensive to build, and everything comes from Fleabay or The big river site.

I can take pictures of the wiring in one of mine or I can post up a schematic that is easy to follow.
Let me know if there is any interest, and maybe I'll make a thread for building one...
Attachments
Ken Mc.

WTB Kershaw 2120 MACHO Lockback Parts knife
I need a pile side scale. THX!

Jeffinn
Posts: 73
Joined: Fri Nov 10, 2017 3:16 am
Location: Roseville, Mi

Re: Which Buffing Wheels To Use

Postby Jeffinn » Thu Dec 07, 2017 7:11 pm

I'm interested! Can you post or send me the schematic?
Jeff
If it ain't broke, you're not trying!

User avatar
americanedgetech
Gold Tier
Gold Tier
Posts: 1528
Joined: Mon Sep 04, 2017 1:40 am
Location: Florida Pan Handle
Contact:

Re: Which Buffing Wheels To Use

Postby americanedgetech » Thu Dec 07, 2017 10:09 pm

I'll draw one up, and post it. I use Auto Cad to draw these kind of things so it's straight forward.

Give me a day or so, and I'll make a proper thread with pictures, schematic, a parts list, and my vendors. ::tu::
You plug the controller into the wall, and the item you want to control plugs into the box. Just that simple...
Ken Mc.

WTB Kershaw 2120 MACHO Lockback Parts knife
I need a pile side scale. THX!

Jeffinn
Posts: 73
Joined: Fri Nov 10, 2017 3:16 am
Location: Roseville, Mi

Re: Which Buffing Wheels To Use

Postby Jeffinn » Thu Dec 07, 2017 10:39 pm

Looking forward to it Ken!
Jeff
If it ain't broke, you're not trying!

User avatar
americanedgetech
Gold Tier
Gold Tier
Posts: 1528
Joined: Mon Sep 04, 2017 1:40 am
Location: Florida Pan Handle
Contact:

Re: Which Buffing Wheels To Use

Postby americanedgetech » Sat Dec 09, 2017 10:18 pm

Jeffinn wrote:Looking forward to it Ken!
Jeff


Here's the link to the controller... viewtopic.php?f=37&t=54784
Ken Mc.

WTB Kershaw 2120 MACHO Lockback Parts knife
I need a pile side scale. THX!
